Building Instructions

These are 3D Building Instructions for an Alternative Virtual Reality Artist mission model for the FIRST LEGO League 2023-2024 MASTERPIECE competition.

These are 3D Building Instructions for an Alternative Movie Set mission model for the FIRST LEGO League 2023-2024 MASTERPIECE competition.

These are Alternative 3D Building Instructions for the Light Show mission model for the FIRST LEGO League 2023-2024 MASTERPIECE competition to be used with the Chain Monster Box Robot. A single accurate rotation of the white arrow indicates a perfect mission completion.

These are 3D Building Instructions for an Alternative Augmented Reality Statue mission model for the FIRST LEGO League 2023-2024 MASTERPIECE competition.

These are 3D Building Instructions for an Alternative 3D Cinema mission model for the FIRST LEGO League 2023-2024 MASTERPIECE competition.

In this attachment two knob wheels "(32072 ) Technic Gear 4 Knob" engage at 90 degrees angle. One of the knob wheels is a part of the robot and the other is a part of a pinless active attachment. The purpose of this attachment is to demonstrate How NOT to build attachments.

Build the attachment and experiment. See for yourself how it "jumps" up and down when the knob wheels are rotating and you hold the lever by hand.

This is an attachment for Kufar - Easy SPIKE Prime out-of-box robot. The attachment solves the light show mission using rubber bands! It works well, but it does depend on how new your model is. On newer models it can work with only 2 red rubber bands or even with 2 yellow and 2 red. Find the best combination for your field.

The trigger for the light show mechanism also releases Anna the Museum Curator and the masterpiece on the pedestal.

This is an attachment for Kufar - Easy SPIKE Prime out-of-box robot. It is an experiment we did that didn't work out for the FLL 2023-2024 MASTERPIECE field, but is interesting nonetheless. It shows how you can take an out-of-box robot and put a steering mechanism on it.

Luly is a new STEAM competition robot from LEGO Education SPIKE Prime. We would use in some of the courses. This version of Luly have some light shields to protect the color sensor from ambient light. Check out the courses below and see how Luly is used to complete in a competition.

This is a simple pinless active attachment for the SUV Box Robot.

In this attachment we use "(32498) Technic Gear 36 Tooth Double Bevel". There are four pins added to the wheel and it it this pins that engage with the "(32072 ) Technic Gear 4 Knob". The more important thing is that the knob wheel and the gear wheel are parallel to each other.

While the motor rotates the attachment has 4 points of contact (instead of one or two when two Knob Wheels are in contact) with the robot knob wheel. There are no forces that drive the attachment to jump and lose engagement with the robot.

These are 3D Building Instructions for an Alternative Music Concert Lights and Sounds mission model for the FIRST LEGO League 2023-2024 MASTERPIECE competition.
